APPLICATORS, CUTTING, STRIPPING AND CRIMPING EQUIPMENT
End and side feed |
APPLICATORS FOR STANDARD CRIMPING TERMINALSSpecifications Applicators compatible to industry standard Sizes: end-feed applicator - 5.90’ (15.0 cm) x 2.75’ (7.0 cm) x 6.30’ (16.0 cm) side-feed applicator - 5.90’ (15.0 cm) x 4.30’ (11.0 cm) x 5.71’ (14.5 cm) Stroke: 1.57’ (40 mm) Weight: 11 lbs. (5 Kg) approx. |
Electromechanical presses |
CRIMPING PRESSESSpecifications Dimensions: 24.80’ (63.0 cm) x 11.42 (29.0 cm) x 10.24’ (26.0 cm) |
 |
Specifications Dimensions: 7.87’ (20.0 cm) x 11.81 (30.0 cm) x 22.05’ (56.0 cm) Power supply: 110 – 230 – 380V / 50-60Hz – motor 0.75 kW Stroke: 1.57’ (40 mm) Weight: 90 lbs. (41 Kg) approx. |
 |
PNEUMATIC CRIMPING MACHINESpecifications Dimensions: 5.12’ (13.0 cm) x 5.51’(14.0 cm) x 10.63’ (27.0 cm) Crimping force: 2640 lbs. (12.000N) Max wire cross section: up to 9 AWG (6.0 mm²) Air supply: 6 Bar Weight: 35 lbs. (16 Kg) approx |
 |
STRIPPING AND CRIMPING EQUIPMENTSpecifications Dimensions: 33.86’ (86.0 cm) x 19.69’ (50.0 cm) x 17.72’ (45.0 cm) Power supply: 110 – 230 – 50-60Hz – motor 0.75 kW Crimping force: 4400 lbs. (20.000N) Wire cross section: 26 - 14 AWG (0.12 – 2.5 mm²) Weight: 242 lbs. (110 Kg) approx. |
 |
BENCH TOP STRIPPING EQUIPMENTSpecifications Dimensions: 13.39’ (34.0 cm) x 5.91 (15.0 cm) x 6.70’ (17.0 cm) Power supply: 110V – 230V – 50-60Hz – 60W Wire dia.: up to 6AWG (4.2 mm) Stripping length: 0.059’ (1.5 mm) to 0.393’ (10.0 mm) Wire cross section: 30AWG (0.05 mm²) 13AWG to 2.5 mm² Minimum wire length: 0.51’ (13.0 mm) Weight: 14.74 lbs. (6.7 Kg) approx. |
 |
AUTOMATIC CUTTING MACHINESpecifications Dimensions: 13.78’ (35.0 cm) x 9.84 (25.0 cm) x 12.60’ (32.0 cm) Power supply: 110V – 230V – 50 - 60Hz – 250W Cutting width: max. 3.94’ (100 mm) Cutting length: up to 330 ft. (100 m) Cutting height: up to 7AWG (10 mm²) Weight: 55.0 lbs. (25.0 Kg) approx. |
Other equipment are available upon request.
